Santa Maria E-Gravel
£3,299.00
Prepare: 1-2 Business Days
Shipping: 3-5 Business Days
The Deruiz Santa Maria E-Gravel bike was designed for all your off-road adventures. Lightweight, functional and built with top quality components but without the heavy price tag.
Our well chosen components such as the high performing Continental Terra Trail tires, Sram Rival 11-speed gears, and Tektro hydraulic disc brakes makes this a cool bike to ride on those country roads.
50cm Size: Suitable for heights of 170-180 cm.
56cm Size: Suitable for heights of 180-190 cm.
Related Products
Why Deruiz E-Gravel?
Bafang H600 motor
250W, 30Nm
36V 7Ah 252Wh
Hidden battery
11-speed
SRAM Rival
All-Carbon
Frame, fork, handlebar, seat post
Continental Tires
Terra Trail tires
Components
|
Gender
Unisex |
Main Information
Type: E-bike 25km/h(EU) Wheel size: 700C Size: 50cm / 56cm Color: Obsidian Black / Skyscraper Grey Number of gears: 11 speed gears |
|
Dimension
Bike weight: 13.1 kg (50cm) / 13.2 kg (56cm) |
Frame
Suspension brand: Without suspension Type: Diamond frame Material Type:Deruiz Carbon Fiber frame and fork construction, integrated cable routing, front thru-axle 12*14*28mm, flat mount brakes, up to 700×40 tires, BB8624 GUB ceramic press- fit bottom bracket |
|
Motor
Brand: Bafang Model: H600 (RM G370.250.DC) Type: rear-wheel drive hub motor Voltage: 36 V Wattage: 250 W Torque: 30 N.m Weight: 2 Kg Open size: 138 mm Hall sensor: Yes Speed sensor: Yes |
Battery
Model: Deruiz Type: Lithium Ion 18650 cells Cell brand: Samsung Cell capacity: 3500mah Battery capacity: 252 Wh Battery installation:Removable in-tube battery Battery weight: 1.3 kg Battery size: 375×45×45 mm |
|
Display
Model: DM02 Type: TFT Level: 0-5 Feature: Double-side button control |
Charger
Type: 36V 2A Deruiz charger with EU plug |
|
Speed sensor
Brand: Kclamber Model: SPSP1 |
Range
Range (km):75 km (with display level 1); 25 km (with display level 5) – Test rider weight: 100kg |
|
Fork
Type: Carbon fork Type: Deruiz carbon fork, 700×40 maximum tire size, flat mount disc brakes, 12×100 mm thru axle |
Rear Derailleur
Drive type: Derailleur Number of gears: 11 Brand: Sram Type: Rival 1 |
|
Shifter
Model: SRAM Rival eTap AXS |
Crankset
Model: Prowheel RPP-FD16A-TT Chainring size: 42T |
|
Chain
Model: KMC X11, 11-Speed |
Cassette
Cassette size: 11-42T Model: SRAM Rival, 11-speed |
|
Front Brakes
Brand: Sram Type: Rival eTap AXS Braking system: Hydraulic disc brake Brake disc diameter: 160mm |
Rear Brakes
Brand: Sram Type: Rival eTap AXS Braking system: Hydraulic disc brake Brake disc diameter: 160mm |
|
Handlebars
Model: Carbon one-piece integrated stem handlebar construction, length: 90mm, width: 400mm, drop angle: 3 |
Saddle
Saddle: Selle Royal Asphalt GF |
|
Seat Post
Diameter: 27.2*300mm Material: Carbon |
Rims
Model: Alloy, 700c, 35c-43c |
|
Front Tires
Size: 700C Tire width: 40mm Model: Continental Terra Trail shield wall 700*40C |
Rear Tires
Size: 700C Tire width: 40mm Model: Continental Terra Trail shield wall 700*40C |
|
Power Supply
Plug type: EU plug |
Scope of Delivery
including pedals: Yes |
|
Model Year
2023 |
